Description
Product details
| Gross weight | 10.99 kg |
| Net weight | 6.75 kg |
| EAN | 5702428483186 |
| Gross weight | 10.99 kg |
| Net weight | 6.75 kg |
| EAN | 5702428483186 |
| Actuator system | 2 EVM pilot sol valve module |
| Brand | ICV Flexline |
| Cv value [gal/min] | 40.6 gal/min |
| Ext pilot pressure connection | Weld nipple (P2 Port) |
| Kv value [m³/h] | 35 m3/h |
| Manual operation option | Manual open spindle |
| Opening configuration | 1-step (optional setting) 2-step (default) |
| Packing format | Single pack |
| Parts Program name | ICLX |
| Product accessories | ICM / ICS / ICLX accessories |
| Product description | Function Module |
| Product group | Press. and temp. regul. valves |
| Product name | Function module |
| Quantity per packing format | 1 pc |
| Refrigerants | R134a R22 R401A R402A R404A R407A R407B R407C R407F R409A R410A R421A R502 R507 R717 R744 |
| Serviceable | ICM / ICS / ICLX spare parts |
| Step 1 opening degree (~) [%] | 10 % |
| Step 2 initialization | Delta p <1.25 bar (18 psig) |
| Type | ICLX 65 |
| Used for product | ICV 65 |
| Used for product comments | With top assembly |
| Valve operation | Solenoid operated |
| Actuator system | 2 EVM pilot sol valve module |
| Brand | ICV Flexline |
| Cv value [gal/min] | 40.6 gal/min |
| Ext pilot pressure connection | Weld nipple (P2 Port) |
| Kv value [m³/h] | 35 m3/h |
| Manual operation option | Manual open spindle |
| Opening configuration | 1-step (optional setting) 2-step (default) |
| Packing format | Single pack |
| Parts Program name | ICLX |
| Product accessories | ICM / ICS / ICLX accessories |
| Product description | Function Module |
| Product group | Press. and temp. regul. valves |
| Product name | Function module |
| Quantity per packing format | 1 pc |
| Refrigerants | R134a R22 R401A R402A R404A R407A R407B R407C R407F R409A R410A R421A R502 R507 R717 R744 |
| Serviceable | ICM / ICS / ICLX spare parts |
| Step 1 opening degree (~) [%] | 10 % |
| Step 2 initialization | Delta p <1.25 bar (18 psig) |
| Type | ICLX 65 |
| Used for product | ICV 65 |
| Used for product comments | With top assembly |
| Valve operation | Solenoid operated |
Kv value [m³/h]: 35.000
Product details
| Gross weight | 10.99 kg |
| Net weight | 6.75 kg |
| EAN | 5702428483186 |
| Gross weight | 10.99 kg |
| Net weight | 6.75 kg |
| EAN | 5702428483186 |
| Actuator system | 2 EVM pilot sol valve module |
| Brand | ICV Flexline |
| Cv value [gal/min] | 40.6 gal/min |
| Ext pilot pressure connection | Weld nipple (P2 Port) |
| Kv value [m³/h] | 35 m3/h |
| Manual operation option | Manual open spindle |
| Opening configuration | 1-step (optional setting) 2-step (default) |
| Packing format | Single pack |
| Parts Program name | ICLX |
| Product accessories | ICM / ICS / ICLX accessories |
| Product description | Function Module |
| Product group | Press. and temp. regul. valves |
| Product name | Function module |
| Quantity per packing format | 1 pc |
| Refrigerants | R134a R22 R401A R402A R404A R407A R407B R407C R407F R409A R410A R421A R502 R507 R717 R744 |
| Serviceable | ICM / ICS / ICLX spare parts |
| Step 1 opening degree (~) [%] | 10 % |
| Step 2 initialization | Delta p <1.25 bar (18 psig) |
| Type | ICLX 65 |
| Used for product | ICV 65 |
| Used for product comments | With top assembly |
| Valve operation | Solenoid operated |
| Actuator system | 2 EVM pilot sol valve module |
| Brand | ICV Flexline |
| Cv value [gal/min] | 40.6 gal/min |
| Ext pilot pressure connection | Weld nipple (P2 Port) |
| Kv value [m³/h] | 35 m3/h |
| Manual operation option | Manual open spindle |
| Opening configuration | 1-step (optional setting) 2-step (default) |
| Packing format | Single pack |
| Parts Program name | ICLX |
| Product accessories | ICM / ICS / ICLX accessories |
| Product description | Function Module |
| Product group | Press. and temp. regul. valves |
| Product name | Function module |
| Quantity per packing format | 1 pc |
| Refrigerants | R134a R22 R401A R402A R404A R407A R407B R407C R407F R409A R410A R421A R502 R507 R717 R744 |
| Serviceable | ICM / ICS / ICLX spare parts |
| Step 1 opening degree (~) [%] | 10 % |
| Step 2 initialization | Delta p <1.25 bar (18 psig) |
| Type | ICLX 65 |
| Used for product | ICV 65 |
| Used for product comments | With top assembly |
| Valve operation | Solenoid operated |
