Description
Product details
| Gross weight | 8.55 kg |
| Net weight | 8.5 kg |
| EAN | 5702421555231 |
| Gross weight | 8.55 kg |
| Net weight | 8.5 kg |
| EAN | 5702421555231 |
| Approval standard | DIN EN 1092-2 |
| Connection size | 50 |
| Connection types | Flange |
| FVF DN50 PN16 with Plug | |
| Diameter [mm] | 50 mm |
| Kvs values [m³/h] | 54 m3/h |
| Manufacturer’s name | Danfoss |
| material | Grey cast iron EN-GJL-250 (GG25) |
| Media temperature [°C] [Max] | 300 °C |
| Media temperature [°C] [Min] | -10 °C |
| Medium alternative | Glycolic water up to 50% |
| Mesh size [mm] | 0.87 mm |
| Number of meshes [n/cm²] | 64 |
| Permissible media | Circulation water |
| Pressure nominal [bar] | 16 bar |
| Product group | Auxiliary Products |
| Strainer type | With plug |
| Type | FVF |
| Approval standard | DIN EN 1092-2 |
| Connection size | 50 |
| Connection types | Flange |
| FVF DN50 PN16 with Plug | |
| Diameter [mm] | 50 mm |
| Kvs values [m³/h] | 54 m3/h |
| Manufacturer’s name | Danfoss |
| material | Grey cast iron EN-GJL-250 (GG25) |
| Media temperature [°C] [Max] | 300 °C |
| Media temperature [°C] [Min] | -10 °C |
| Medium alternative | Glycolic water up to 50% |
| Mesh size [mm] | 0.87 mm |
| Number of meshes [n/cm²] | 64 |
| Permissible media | Circulation water |
| Pressure nominal [bar] | 16 bar |
| Product group | Auxiliary Products |
| Strainer type | With plug |
| Type | FVF |
