Description
Product details
| Gross weight |
0.61 kg |
| Net weight |
0.61 kg |
| Body material |
AISI 304 |
| Connection standard |
BSP |
|
VRH 5 inline 30-120 Bar |
| Flow [gpm] [Max] |
1.3 gal/min |
| Flow [l/min] [Max] |
5 L/min |
| Inlet connection size [in] |
3/8 in |
| Media temperature [°C] [Max] |
50 °C |
| Media temperature [°F] [Max] |
122 °F |
| Operating pressure [barg] [Max] |
100 barg |
| Operating pressure [barg] [Min] |
25 barg |
| Operating pressure [psig] [Max] |
1450 psig |
| Operating pressure [psig] [Min] |
362 psig |
| Outlet connection size [in] |
3/8 in |
| Product group |
Valve |
| Product name |
Pressure operated valves |
| Type |
VRH |
| Type designation |
VRH 5 30-120 bar |
| Body material |
AISI 304 |
| Connection standard |
BSP |
|
VRH 5 inline 30-120 Bar |
| Flow [gpm] [Max] |
1.3 gal/min |
| Flow [l/min] [Max] |
5 L/min |
| Inlet connection size [in] |
3/8 in |
| Media temperature [°C] [Max] |
50 °C |
| Media temperature [°F] [Max] |
122 °F |
| Operating pressure [barg] [Max] |
100 barg |
| Operating pressure [barg] [Min] |
25 barg |
| Operating pressure [psig] [Max] |
1450 psig |
| Operating pressure [psig] [Min] |
362 psig |
| Outlet connection size [in] |
3/8 in |
| Product group |
Valve |
| Product name |
Pressure operated valves |
| Type |
VRH |
| Type designation |
VRH 5 30-120 bar |
Flow [gpm] [Max]: 1.300, Flow [l/min] [Max]: 5.000, Inlet connection size [in]: 3/8 in, Operating pressure [barg] [Min]: 25, Operating pressure [barg] [Max]: 100, Operating pressure [psig] [Min]: 362, Operating pressure [psig] [Max]: 1450, Outlet connection size [in]: 3/8 in
Product details
| Gross weight |
0.61 kg |
| Net weight |
0.61 kg |
| Body material |
AISI 304 |
| Connection standard |
BSP |
|
VRH 5 inline 30-120 Bar |
| Flow [gpm] [Max] |
1.3 gal/min |
| Flow [l/min] [Max] |
5 L/min |
| Inlet connection size [in] |
3/8 in |
| Media temperature [°C] [Max] |
50 °C |
| Media temperature [°F] [Max] |
122 °F |
| Operating pressure [barg] [Max] |
100 barg |
| Operating pressure [barg] [Min] |
25 barg |
| Operating pressure [psig] [Max] |
1450 psig |
| Operating pressure [psig] [Min] |
362 psig |
| Outlet connection size [in] |
3/8 in |
| Product group |
Valve |
| Product name |
Pressure operated valves |
| Type |
VRH |
| Type designation |
VRH 5 30-120 bar |
| Body material |
AISI 304 |
| Connection standard |
BSP |
|
VRH 5 inline 30-120 Bar |
| Flow [gpm] [Max] |
1.3 gal/min |
| Flow [l/min] [Max] |
5 L/min |
| Inlet connection size [in] |
3/8 in |
| Media temperature [°C] [Max] |
50 °C |
| Media temperature [°F] [Max] |
122 °F |
| Operating pressure [barg] [Max] |
100 barg |
| Operating pressure [barg] [Min] |
25 barg |
| Operating pressure [psig] [Max] |
1450 psig |
| Operating pressure [psig] [Min] |
362 psig |
| Outlet connection size [in] |
3/8 in |
| Product group |
Valve |
| Product name |
Pressure operated valves |
| Type |
VRH |
| Type designation |
VRH 5 30-120 bar |
