Name: 5.512 (140mm) x 58.25 x 3.937 (100mm) DA Hydraulic Cylinder 207-63- x 9020 PC300 RH
Brand: mrosupplyyard.com
SKU: 904043
Price: 209.99 USD
Availability: InStock

5.512 (140mm) x 58.25 x 3.937 (100mm) DA Hydraulic Cylinder 207-63- x 9020 PC300 RH

SKU: 904043 Category: hot sale

Description

5.512″ (140mm) x 58.25″ x 3.937″ (100mm) DA HYDRAULIC CYLINDER
New, welded cylinder with bolt-on gland cap. “207-63-X9020 PC300 R.H.” written on cylinder barrel.

SPECIFICATIONS
Double Acting Bore x Stroke140mm (5.512″) x 58-1/4″ Barrel Thickness13mm (0.512″) Pressure 3000 PSI max. Rod Dia. 100mm (3.937″)	Ports 1″ Four-Bolt Split Flange, Code 61 Retracted Length 84″ Shpg. 710 lbs.

END MOUNTINGS
Rod End Tang Max Thickness 4-9/16″ Pin Center to Tang End 3-5/16″ Pin Hole 100mm (3.937″)	Base End Tang Max Thickness 4-3/16″ Pin Center to Tang End 3-5/16″ Pin Hole 90mm (3.543″)
