Description
Jomar 1/2 Inch P-501G Series Lead Free Brass Press Connection Horizontal Swing Check Valves – Pack of 2
Optimize your systems by choosing Jomar Valve products for your projects. Made with high quality alloys and materials, longevity and peak performance are ensured no matter the application. With third-party testing, inspection and validation, Jomar provides a robust lineup of UL, CSA, FM and NSF certified products to customers worldwide.
These 1/2″ P-501G Series Horizontal Swing check valves with Press connections are rated for 200 WOG and are Truesdail Certified – NSF 61 & NSF 372. Made from lead free brass, they feature a on-piece body design and a metal-to-metal disc seal.
Each pack includes 2 105-003G brass Horizontal Swing Check Valves.
Features
- Dezincification Resistant Brass Alloy
- EPDM O-Ring Seal
- Wetted Surfaces Contain Less than .25% Lead Content
- Heavy Pattern Cast Brass Construction
- One-Piece Body Design
- Metal-to-Metal Disc Seal
- Residential and Commercial Applications
- Truesdail Certified – NSF 61 & NSF 372
Specifications
| MPN | 105-003G |
|---|---|
| Size | 1/2″ |
| Connection Type | Press |
| Type | Horizontal Swing |
| Pressure Rating | 200 WOG |
| Class | 125 |
| Body Material | Lead Free Brass |
| Trim Material | Brass |
| Seat Material | Brass |
| Seal Material | EPDM |
Certifications
- Conforms to IAPMO PS 117
- Truesdail Certified – NSF 61 & NSF 372
