Description
– PBH-420-1 Bag Filter Assembly
– 20 Bag Vessel, 20″ Long
– 1” NPT Inlet / Outlet
– Comes Complete with Gauge, Wrench and 3/8″ Drain Valve
– Cap Manufactured from Reinforced Polypropylene
– Bag Manufactured from Lightweight Corrosion Resistant Polypropylene
– Gauge Manufactured from Bismuth Brass (Lead-Free)
– Offer Outstanding Chemical Campatibility
– Ideal for Use in a Variety of Low-Flow Applications
– Economically Prices
– Filter Bags are Avaliable in Polypropylene Felt, Absolute-Rated High-Efficiency Polypropylene and Nylone Monofilament Mesh-Edeal for Filtration and Straining Applications from 1 to 800 Microns
– Accepts 4″ x 18-1/2″ (102mm x 470mm) Bag Filter
– Max Temperature: 100 °F (37.8 °C)
– Max Pressure: 90 psi (6.2 bar)
– Initial ∆P (psi) @ Flow Rate (gpm): 1 psi @ 15 gpm (0.07 bar @ 57 L/min)
– NSF Approved for Material and Structural Integrity
– Standard 1 Housings per Case- Replaces the obsolete 150360
